Mineral powder briquetting machine

Charcoal Briquette Machine can press materials like quicklime powder, dolomite dust, bauxite, nonferrous metal powder, oxide iron powder and iron sheet.

Theoretical yield:2-28(t/h)

Output:1-20 h/t

Motor power:5.5-75 (kw)

Technological Features:Pulverized coal, coking coal, iron powder,desulfurization gypsum, cryolite,sludge, etc.

  • Coal Dust
Get Pricelist
If you are interested in our products, please email us at market@sinoftm.com.

The mineral powder briquetting machine (including the manganese mineral powder ball press machine and slag, fluorite powder, carbon dust, iron powder briquette machine) designed based on different minerals' properties is popular among users because it's widely applied to process minerals such as desulphurization gypsum, quick lime, coal ash, coal slag, carbon dust, iron powder, steel slag, fluorite, magnesium powder, red soil nickel powder and chromium powder.

1. Parameters are adjustable according to different materials.

2. Various specifications can meet different requirements.

Mineral powder briquetting machine

Technical Parameters

Model Roll diameter
(mm)
Roll width
(mm)
Total pressure
(t)
Main motor power
(kw)
Output
(t/h)
Weight
(t)
GY520-150 520 196 150 55 2.2-3.5 13
GY650-220 650 200 220 110 4-6.5 19.2
GY750-300 750 280 300 185 6-8.5 34
GY1000-350 1000 440 350 250 10-15 50.8
GY1000-450 1000 504 450 280 14-17 58.5
GY1000-500 1000 504 500 315 15-20 58.5
GYS1000-500 1000 600 500 280 17-21 56.5
GY1000-540 1000 900 540 185Kw×2 30-35 60
GY1200-800 1200 900 800 280Kw×2 40 110
GY1400-1000 1400 1000 1000 400Kw×2 50 156
